C1000 Gold (2022)
1000W Gold Fully-Modular ATX PSU
Optionen auswählen
C1000 Gold (2022) Übersicht
Dieses Netzteil liefert 1000 Watt reine, konstante Leistung und ist ideal für Gaming- und Workstation-PCs mit mehreren GPUs und leistungsstarken CPUs. Das C1000 unterstützt die neuesten GPUs, einschließlich der NVIDIA RTX 3090 und AMD GPUs bis hin zur 6900 XT.
Technische Daten
Output Connectors
24-pin ATX power
1
4+4-pin CPU power
2
6+2-pin PCIe power
6
SATA power
6
Peripherals
6
Cable Specs
24-pin ATX power
600 mm, Nylon sleeving
4+4-pin CPU power
700 mm, Nylon sleeving
6+2-pin PCIe power
650 + 150 mm, Nylon sleeving
SATA power
500 + 150 mm
Peripherals
500 + 150 mm
AC Input Rating
100 - 240Vac
13A-6.5A 50Hz-60Hz
DC Output Rating
+3.3V and +5V
22A (120W)
+12V
83.5A (1002W)
-12V
0.3A (3.6W)
5Vsb
3A (15W)
Total
1000W
Operation
PF Correction
Active @0.96
MTBF
100,000 hours
Temperature
0 - 50 °C (derating from 100% to 80% from 40 °C to 50 °C)
Energy Efficiency
Rating
80 Plus Gold
20% loading
91.97% @115Vac
50% loading
91.79% @115Vac
100% loading
88.52% @115Vac
Fan Specs
Dimensions
135 x 135 x 25 mm
Speed
0-2300 ± 10% RPM
Airflow
93.02 CFM (Tpy.)
Noise
44.5 dBA max
Bearing
Fluid Dynamic Bearing (FDB)
General
Dimensions
150 x 150 x 86mm
Material(s)
Steel, PCB and Plastic
Compliance Standard
ATX12V v2.52 / EPS12V v2.92
Regulation & Certification
cTUV-SUDus / CUL (UL60950/62368-1) / TUV / (EN60950/62368-1) / CB/ (IEC 950/62368-1) / CCC / CEC / BSMI / RCM / EAC / CE / LVD / UKCA
Warranty
10 years
Model Number
PA-0G1BB
UPC
UPC (TW)
815671017512
UPC (CN)
815671017444
UPC (AR)
815671017451
UPC (US)
815671017468
UPC (EU)
815671017475
UPC (UK)
815671017482
UPC (AU)
815671017499
UPC (JP)
815671017505
UPC (WO)
815671017536
UPC (IN)
815671017529
EAN
EAN (TW)
5060301697823
EAN (CN)
5060301697755
EAN (AR)
5060301697762
EAN (US)
5060301697779
EAN (EU)
5060301697786
EAN (UK)
5060301697793
EAN (AU)
5060301697809
EAN (JP)
5060301697816
EAN (WO)
5060301697847
EAN (IN)
5060301697830
